About US
We are a direct factory for Light Emitting Diodes (LEDs), ensuring quality assurance, and support OEM and ODM customization. Welcome to inquire.
0201 Series
Product Introduction
| Product | Size | Color | λd(nm)/ | Vf(V) | IV(mcd) | Viewing | IF | ||
| (L*W*Hmm) | CCT(K)/ | Angle | (mA) | ||||||
| CIE(X,Y) | 2θ1/2 | ||||||||
| Min | Max | Min | Max | (deg) | |||||
| 001.R001 | 0.65*0.35*0.4 | Red | 618-635 | 1.8 | 2.4 | 50 | 80 | 120° | 5 |
| 001.G001 | 0.65*0.35*0.4 | Greed | 512-525 | 2.5 | 3.5 | 150 | 180 | 5 | |
| 001.B001 | 0.65*0.35*0.4 | Blue | 460-470 | 2.5 | 3.5 | 70 | 90 | 5 | |
| 001.O001 | 0.65*0.35*0.4 | Orange | 600-610 | 1.8 | 2.4 | 70 | 90 | 5 | |
| 001.Y001 | 0.65*0.35*0.4 | Yellow | 580-595 | 1.8 | 2.4 | 40 | 90 | 5 | |
| 001.YG001 | 0.65*0.35*0.4 | Yellow Greed | 565-575 | 2.5 | 3.5 | 11.5 | 70 | 5 | |
| 001.W000 | 0.65*0.35*0.4 | Cool White | 5000-6500 | 2.5 | 3.5 | 150 | 300 | 5 | |
| 001.W000 | 0.65*0.35*0.4 | Warm White | 2700-3500 | 2.5 | 3.5 | 150 | 300 | 5 | |
| 001.W000 | 0.65*0.35*0.4 | White | 4000-4500 | 2.5 | 3 | 270 | 400 | 5 | |
| 001.W000 | 0.65*0.35*0.4 | White | 6500-12000 | 2.5 | 3 | 270 | 400 | 5 | |
| 001.W000 | 0.65*0.35*0.4 | White | 12000-25000 | 2.5 | 3 | 270 | 400 | 5 | |
| 001.W000 | 0.65*0.35*0.4 | White | 100000 | 2.5 | 3 | 270 | 400 | 5 | |
